Champion Magnum

A magnitude of performance above the regular 'Champion'.

share this product

Features

Product specifications

The Magnum owner is the owner of 23 kg of perfectly machined and finished parts, hand built and offering a magnitude of performance above the regular 'Champion'.

Total weight

Approx. 23 kg

Dimensions

Width
18.5 inches
Depth
15.3 inches
Height
6.3 inches

Speed ranges

33 ⅓ and 45 rpm (78 rpm optional)

Material/color

Available as Transparent and Black version

Technical specifications
Construction Details Resonance optimised chassis`s shape, belt driven
Speed ranges 33 ⅓ and 45 rpm (78 rpm optional)
Drive unit Separately housed synchronous motor in a massive stainless steel case
Bearing Polished and hardened steel, polished bearing housing, sintered bronze, inverted
Platter GS-PMMA / acrylic, Surface CNC-precision milled. 2.8 inches / 70 mm
Speed accuracy (measured) ± 0.1 %
Signal to noise ratio 83 dB
Total weight Approx. 23 kg
Dimensions (w/d/h in inches) Approx. 18.5 x 15.3 x 6.3
Dimensions (w/d/h in mm) Approx. 470 x 390 x 160
Warranty 5 years*
